Mono marine subwoofer amplifier — 750 watts RMS x 1

Providing plenty of clean power is key to getting great bass on a boat. JL Audio's mono MHD750/1 marine amplifier will push 750 watts RMS to your subwoofer from a 2" tall chassis with a footprint the size of a sheet of computer paper. And this amp's frequency response extends up to 8,000 Hz, so it can also drive a high-performance mid bass or midrange driver. Variable high- and low-pass filters, along with a switchable infrasonic filter, allow the amp to adapt to just about any application.

PRODUCT DETAILS:

• mono marine subwoofer amplifier
  • 750 watts RMS x 1 at 1.5 to 4 ohms
• Class D amp design with Single Cycle Control and R.I.P.S. (Regulated, Intelligent Power Supply)
  • frequency response: 6-8,000 Hz
• variable high- and low-pass filter (50-500 Hz, 12 or 24 dB/octave)
• switchable infrasonic filter (30 Hz, 24 dB/octave)
• differential-balanced inputs help eliminate noise
• removable power and speaker plugs
• wiring, fuse, and hardware not included with amplifier
  • 4-gauge power and ground leads and a 60-amp fuse recommended
• dimensions: 10-3/4"W x 2"H x 9-1/2"D
• Monoblock class-D amplifier
• Power/Ground/Turn-On plug
• Speaker connection plug
• 4 Mounting feet
• 2.5mm Allen-wrench
• 4mm Allen-wrench
• four M4x40mm Flat head machine screws
• JL Audio badge
• Owner's manual
